Ürün Kodu: BP2S-D0
GTIN: 74983591497

Dome-Top® Barb Ty Push Mount Cable Ties; Application: General; Color: Black; Cross Section: Standard; Environment: Indoor or outdoor; Head Height (In.): 0.39; Head Height (mm): 9.8; Locking Style: Locking; Material: Weather Resistant Nylon 6.6; Maximum Bundle Diameter (In.): 2 Inch; Maximum Bundle Diameter (mm): 51 Millimeters; Maximum Panel Thickness (In.): 0.13; Maximum Panel Thickness (mm): 3.2; Min. Loop Tensile Strength Lbs. (N): 50 (222); Minimum Bundle Diameter (In.): 0.06 Inch; Minimum Bundle Diameter (mm): 1.5 Millimeters; Minimum Loop Tensile Strength (lb): 50 Pound; Minimum Loop Tensile Strength (N): 222 Newton; Nominal Hole Diameter (In.): 0.26; Nominal Hole Diameter (mm): 6.5; Overall Length (In.): 8.5 Inch; Overall Length (mm): 216 Millimeters; Overall Width (In.): 0.19 Inch; Overall Width (mm): 4.7 Millimeters; Product Type: Cable Ties; Package Quantity: 500

Teknik Özellikler (ETIM)

Colour
Black
Model
Without toothing
Halogen free
Yes
Length belt/tape/tie (mm)
216
Text strip
None
Surface protection
Untreated
Material quality
Polyamide (PA)
Material_EF002169
Plastic
MIN - Operating temperature (°C)_EF002393
-60
MAX - Operating temperature (°C)_EF002393
85
Type of fastening
Plug-in anchor/plug-in cam
Inflammability class of insulation material according to with UL94
V2
Tie thickness (mm)
1.3
Solvable fastener
No
Transparent
No
Band closure
Steel nose
Max. bundle diameter (mm)
51
MIL approval
No
UL approval
Yes
UV-stable according to ASTM D6779
No
VG approval
No
Band width (mm)
4.7
MIN - Mounting temperature (°C)
-20
MAX - Mounting temperature (°C)
85
Fluorescent
No
Min. tensile strength (N)
222
Min. bundle diameter (mm)
Length belt/tape/tie (inch)
MIN - Operating temperature (°F)_EFI02393
-76
MAX - Operating temperature (°F)_EFI02393
185
Tie thickness (inch)
Max. bundle diameter (inch)
Band width (inch)
MIN - Mounting temperature (°F)
-4
MAX - Mounting temperature (°F)
185
Min. tensile strength (lb)
Min. bundle diameter (inch)
