Halogen free
Surface protection Tinned
Insulation None
Total length (mm) 20.1
Max. current (Imax) (A)
Flange shape Pin shape
For pull protected connections No
Reel/roll packaging No
Colour insulation
Material_EF002169 Copper
Bolt dimension (metric)
MIN - AWG-range 14
MAX - AWG-range 10
MIN - Nominal cross section (mm²) 2.5
MAX - Nominal cross section (mm²) 6
Suitable for fine strand conductors No
Suitable for flat conductors No
Suitable for high temperatures (to 650 °C) No
Suitable for insulated varnish No
Suitable for solid conductors
Suitable for stranded conductors Yes
Suitable for round conductors Yes
Sleeve form
According to DIN No
Stud size (imperial)
Flange length (mm)
Pin width (flat-pin shape terminal) (mm)
Pin diameter (pin shape terminal) (mm)
Total length (inch) 0.79
MIN - Nominal cross section (in²) 0.0039
MAX - Nominal cross section (in²) 0.0093
Flange length (inch)
Pin width (flat-pin shape terminal) (inch)
Pin diameter (pin shape terminal) (inch)
