Colour Other
Model Internal toothing
Halogen free Yes
Length belt/tape/tie (mm) 102
Text strip None
Surface protection Untreated
Material quality Polyamide (PA)
Material_EF002169 Plastic
MIN - Operating temperature (°C)_EF002393 -60
MAX - Operating temperature (°C)_EF002393 85
Type of fastening None
Inflammability class of insulation material according to with UL94 V2
Tie thickness (mm) 0.9
Solvable fastener No
Transparent Yes
Band closure
Max. bundle diameter (mm) 20
MIL approval Yes
UL approval Yes
UV-stable according to ASTM D6779 No
VG approval No
Band width (mm) 2.4
MIN - Mounting temperature (°C) -20
MAX - Mounting temperature (°C) 85
Fluorescent No
Min. tensile strength (N) 80
Min. bundle diameter (mm)
Length belt/tape/tie (inch) 4
MIN - Operating temperature (°F)_EFI02393 -76
MAX - Operating temperature (°F)_EFI02393 185
Tie thickness (inch) 0.9
Max. bundle diameter (inch) 0.78
Band width (inch) 0.1
MIN - Mounting temperature (°F) -4
MAX - Mounting temperature (°F) 185
Min. tensile strength (lb)
Min. bundle diameter (inch)
